PureLink MAX2 Series - 12 G SDI Output Card MAX2-SOS100

MAX2 4K60 Cross Platform Matrix Router
30
12G SDI Output Card - MAX2-SOS100
Number of Port
4 HDMI ports, 4 Audio out ports
Connector Type
Female SDI connector,
Female phoenix stereo jack
Signal Type
RGB digital Video (DVI and HDMI standards) or
YCbCr digital component Video (HDMI)
Digital Audio
Dolby Digital® Plus, Dolby® TrueHD, DTS-HD
High Res, DTS-HD Master Audio™, up to 8ch
PCM
Audio Extraction
Via phoenix stereo Audio out ports
Maximum Data Rate
3.4 Gbps per color (R,G,B)
Maximum Pixel Clock
165 MHz
Standard
HDMI 2/0b
Switching Speed
Max 200ns
Output DVI Re-clocking
Automatic
Output Peripheral Device Power
600 mA per Output
Output Equalization
Automatic, Max 30m 1920 x1200 @50/60Hz
or 1080p; 8 bit color
HDCP Compatible
HDCP version 2.2
Support Hot Plug Detection
Yes
Single Card Weight
0.5 lbs (0.23 kg)
