PureLink MAX2 Series User Manual

MAX2 4K60 Cross Platform Matrix Router
32
Extenders Specifications
HDBaseT 3.0 Transceiver - MAX2-CTR100
Connector Types
(1) HDBaseT port
(1) Female HDMI port
(1) 5-pin Phoenix for RS-232/Audio out
Signal Type
HDMI, HDBaseT w/Deep Color, 3D, & 4K
Supported Twisted Cable Type
CAT5/5e, CAT6/6e, CAT6a, CAT7
Digital Audio Formats
Dolby Digital®, Dolby Digital EX, Dolby Digital Plus,
Dolby® TrueHD, DTS®, DTS-ES, DTS 96/24, DTS-HD
High Res, DTS-HD Master Audio™, LPCM up to 8
channels
Compliance
HDCP 2.2
Power Injection for CATx Extenders
POE Injector
Maximum Resolution
up to Ultra HD/4K (4096x2160, 4:4:4 @ 50/60Hz)
Maximum Data Rate
18 Gbps
Shipping Dimensions (W x D x H)
6" X 5.4" X 1.25"
Shipping Weight
1.5 lb. (0.68 kg)
