PureMounts PM-WIRE-37 - Solid Brick and Concrete Mounting; Marking and Drilling Holes; Installing Adapter Brackets; Flat Back Screen Installation

3 4
1. For Solid Brick and Concrete Mounting
60mm
(2.4")
60mm
(2.4")
ø 8mm
(ø 5/16")
Drill pilot holes
2
Mark the
exact location of
mounting holes
WARNING
Installers must verify that the supporting surface will safely support the combined weight of
the equipment and all attached hardware and components.
X X
√
W-B
W-C
W-A
2. Installing the Adapter Brackets
2-1 For Flat Back Screens
Top of the TV
M-F
M-G
M-A
M-B
M-C
M-A
M-B
M-C
M-F
M-G
TV
TV
TV
1
P
M
-
W
I
R
E
-
3
7(6
0-
12
0
m
m)
PM-
W
I
R
E
-
52
(1
80-2
20mm
)
