PureMounts PM-WIRE-37 - Bump-out or Recessed Back Screen Installation; Hanging and Securing the TV; Attaching TV to Wall Plate; Cable Management and Maintenance

2-2 For Bump-out or Recessed Back Screens
Tighten all screws but do not over tighten.
· Screw the supporting spacers onto the TV.
Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen.
5
6
3. Hanging the TV onto the Wall Plate
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your distributor if you have any questions.
After the wall mount has been safely secured to the wall, Carefully lift your TV and hook wirerope into the
wall plate rail. Make sure your TV is securely and correctly attached.
4. Cable Management
•
• Fold the tilt supports back once all cables have been installed.
Fold out the tilt supports to access the cables.
