14
Step 11: Next:
• Place the voltmeter positive
lead where the blue wire is
connected.
• Place the negative lead where
the white wire is connected.
• If there is a voltage reading,
inspect the wiring for defects
and replace if necessary.
• If there is no voltage reading,
proceed to the next step.
Step 12: Next:
• Place the voltmeter positive
lead where the blue wire is
connected.
• Place the negative lead where
the white wire is connected.
• If there is a voltage reading,
replace the module assembly.
• If there is no voltage reading,
inspect the wiring, connections,
dual pole connections, and
cables. Replace if necessary.
Step 13: Check the 7-way:
• Place the voltmeter positive
lead where the blue wire is
connected.
• Place the negative lead where
the white wire is connected.
• If there is no voltage reading,
inspect the wiring, connections,
7-way connections, and cable.
Replace if necessary.
