Purkeys DIRECT PLUS - Nosebox Mounting

6
BATTERIES NOT BEING CHARGED
Step 1: Connect the tractor 7-way
cable to the trailer and start the
tractor.
• Place the voltmeter positive
lead on the stud labeled
positive input.
• Place the negative lead on the
negative battery post.
• If there is a voltage reading,
proceed to the next step.
• If there is no voltage reading,
skip to step 8.
Step 5: On the front of the trailer,
remove the hardware holding the
cover assembly to the nosebox
base.
• Place the voltmeter positive
lead where the orange wire is
connected.
• Place the negative lead where
the white wire is connected.
• Check the battery voltage
reading.
• If there is a battery voltage
reading, replace the cover
assembly on the base.
• If there is no voltage reading,
inspect the wiring for defects
and repair any issues.
