www.PyleUSA.com 7
9. [GAIN] Controller, determines the basic volume of CH1/2, adjust it for maximum
volume performance, when the volume gets too loud, the PEAK LED indicator
will keep ashing.
10. [HIGH & LOW] Tone controller, adjust the high frequency and low frequency
for CH1/2.
11. [PAN] Controller, this is the panorama control or balanced control, determines
the position of channel signal within the stereo image. When working in sub-
groups, you can use the PAN controller to assign the signal to just one output,
which gives you additional exibility in recording situations.
1
2
3
4
9
10
11
12
13
5
7
6
8
18
24
23
17
19
22
21
15
14
16
To Next Page
