Part Description Q’ty Part Description Q’ty
1 PCB 1 20 Left Arm Rest Support 1
2 Screw M3X8 2 21 Screw M3X12 3
3 Adhesive Sticker 1 22 Right Arm Rest Support 1
4 LED 1 23
Support Arm Adjustment Knob
1
5 View Meter 1 24 Outer Stem 1
6 Washer 3mm 2 25 Washer 1
7 Screw M3X8 2 26 Inner Stem 1
8 Control Panel 1 27 Lock Nut Interior 1
9 Support Arm(Right Side) 1 28 Lock Nut Exterior 1
10 Nut M4 4 29 Look Nut Cover 1
11 Screw M3X18 4 30 Bushing 1
12 Screw M3X14 1 31 Coil Button(Nut) 1
13 SENS Dial 1 32 Coil Button(Screw) 1
14 Knobs 2 33 Search Coil 1
15 DISC Dial 1 34 Support Arm Pad 1
16 Speaker 1 35 Earphone Jack 1
17 Support Arm(Left Side) 1 36 Battery Compartment 1
18 Screw M3X25 2 37
Battery Compartment Cover
1
19 Red Button/Switch 1
