Pyle PHR105B User Manual

PHR105 B
Function keys panel
1 2 3 4 5
1. Video input selection
2. Menu
3. Power on/off
4. Analog variable decrease
5. Analog variable increase
Methods of remote using
Wire diagram
Features:
Power ON/OFF
Analog variable increase
Menu button
V1/V2 conversion
Analog variable decrease
Switch for mode
(Green) reverse car
PLAYER
CAMERA
(Red) battery+12V
(Black) grounding
(Yellow) video 1 input
(Yellow) video 2 input
10" TFT/LCD Digital Display Screen
High Resolution 1024 x 600 Pixel Display
16:9 Wide Screen Format
RCA Connectors: Audio & Video Connector Input Jacks
Input Modes: AV1, AV2
Easy Touch Button Panel Controls
Built-in IR Transmitter for Wireless Headphones
Built-in Dual Speakers
NTSC/PAL System Compatible
Brightness, Contrast, Color & Tint Adjustments
Power Requirement: DC 12V +/- 10%
Power Consumption: 5W Max
Includes Power and Video Wiring Harness, Remote Control, Universal Stand
Mount & Shroud Headrest Housing Bracket
Monitor Dimensions (W x H x D): 9.7" x 6.3" x 0.8" inches
Housing/Shroud Dimensions (W x H x D): 10.5" x 7.5" x 1.1" inches
Cut-Out Dimensions (W x H x D): 10.15" x 6.3" x 0.8" inches
Sold as: Uint
Weight: 3.15 lbs.
PHR105B

Pyle PHR105B Specifications
