Pyle PLHRQD9B User Manual

Name: Pyle PLHRQD9B
Brand: Pyle
Rating: 4 (1 reviews)

2 pages

To Previous Page

PLHRQD9B

Function keys panel

1 2 3 4 5

1. Video input selection

2. Menu

3. Power on/off

4. Analog variable decrease

5. Analog variable increase

Methods of remote using

Power ON/OFF

Switch for mode

Upward

Leftward

Downward

Video 1 input

Video 3 input

Rightward

Video 2 input

Video 4 input

Video Input 1

Video Input 2

Video Input 3

Video Input 4

Red '+'

Black 'GND'

Blue 'Reverse' Line

Wire diagram
