www.PyleUSA.com
3
WIRING CONNECTIONS
CONTROL PANEL BUTTONS
WIRING DIAGRAM
PRECAUTION
+12V DC
NEGATIVE
EARTH
AMPLIFIER OUTPUT
White: Rear Output
Left
White: Front Output
Left
Red: Right Front Output
Red: Rear Right Output
