Pyle PLMRWB652LEW - Bracket Installation Guide; Part 1: Bracket Assembly; Part 2: Mounting Hole Dimensions

Remark:two types of screws for choice:M5x65/M5x80
P A R T 1.
PART 2.
1.The base of the bracket.
2.The connecting base of the bracket,360 ratation,connect to picture1.
3.The cover of the bracket,is fixed by 4 mounting screws after picture 2 rotates to an angle.
Mounting hole dimension
1 1/3”
(3.4cm) (4.45cm/6cm)
1 3/4” 2 2/5”
360 Rotation
3
2
1
