Pyle PSUFM1043BT User Manual

www.PyleUSA.com4 www.PyleUSA.com 5
CONTROL PANEL
Front board Function:
1. Volume adjustment
2. Treble adjustment
3. Bass adjustment
4. MIC echo adjustment
5. MIC volume adjustment
6. MP3 pause or play
WIRELESS MICROPHONE OPERATION
1. Replace the battery when noise occurs during
use, staccato, or distortion.
2. Turn o the power switch after use.
3. If the microphone is not to be used for a long
period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
4. When you turned ON the power switch and the
power indicator does not light, check the polarity
of the battery installation.
Wireless BT Streaming:
• Instantly Stream Music from Your Wireless BT Devices
• Works with All Your Favorite Wireless BT Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Bluetooth Version: 5.0
• Wireless BT Range: 50'+ Feet
• Wireless BT Network Name: 'Pyle Audio'
What's in the Box:
• Active Speaker Tower
• Wireless Microphone
• Power & Audio Connection Cables
• Detachable Rolling Wheels
• Remote Control
7. MP3 next song/FM next frequency/VOL+
8. USB/SD/MMC card connector
9. AUX/DVD/MP3/FM/BT input select
10. MP3 last song/FM last frequency/Volume-
11. MIC input jack
1
2
3
4
5
6
7
8
9
10
11

Pyle PSUFM1043BT Specifications

General

Product color	Black
Recommended usage	Universal
Multi-Room Streaming (MRS) support	-
Tweeter	Yes
Speaker type	2-way
Number of drivers	2
Speaker placement	Floor
Audio output channels	1.0 channels
Woofer diameter (imperial)	10 \
Tweeter diameter (imperial)	3 \
Impedance	4 Ω
Sensitivity	92 dB
Frequency range	45 - 20000 Hz
RMS rated power	- W
Peak Music Power Output (PMPO)	2000 W
Bluetooth range	15 m
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Compatible memory cards	SD
Connectivity technology	Wired & Wireless
AC input voltage	110 - 220 V
Power source type	AC
Cables included	AC, RCA

Weight and Dimensions

Depth	1066.8 mm
Width	383.54 mm
Height	408.9 mm
