03 04
Control & Function LayoutControl & Function Layout
*VOL-/ VOL+: Buttons for Volume + or Volume -
* / :Button Switches to Previous Song or Next Song
* :Button Switches to Play or Pause
*WIFI: WIFI Signal Indicator
*WPS: WIFI Protected Setup
5. WIFI/ BT/ AUX2/ AUX1 Input Selector
Lets you Select the Desired Input Music Source between WIFI/ BT/
AUX2/ AUX1
6. BASS and TREBLE Controls
Allows You to Boost or Attenuate Bass and Treble for the Desired
Sound.
7.BALANCE
Lets you Adjust the Sound Balance Between the Left and Right of
Amplifier Outputs.
8.MASTER Volume Control
Lets You Control the Overall Volume Level. It Doesn’t Affect the
Volume of MIC.
9.MIC Volume Control
Lets You Adjust the Volume of Connected MIC to the Proper Setting.
10.1/4” PHONE Input Jack
Accepts Headphones with 1/4” Plug.
11.MP3 3.5mm AUX Input Jack
Let You Easily Connect the Computerized MP3 Device ( Player)
Sources, Such as Mobile Phone, Laptop, iPad, Walkman, etc.
12.POWER On/ Off Switch
13.FUSE: Replaceable Power Fuse
The Amplifier Uses a Fuse for Protection Against Surges and Short
Circuit. If the Amplifier Suddenly Turns Off and Will Not Turn On,
Check the Fuse and If Necessary Replace it with a 1.5- Amp,
250- Volt, Fast- Acting, 5x20mm Fuse (Not Supplied).
14.WIFI/ BT Antenna
15.PAGER/ MIXIG
Set to PAGER, the Signal from AUX1 and AUX2 will be Attenuated
By - 12dB and the Signal from MIC will Override to Page ( Auto
Talkover) , It is Good for Paging System, Set to Mixing, the Signal
from AUX1/ AUX2 and MIC will be Existed at the Same Time, It Acts
Like Playing at KARAOKE Event.
16.AC IN Power Plug
Connect to AC 110V/ 60Hz, or AC 230V/50Hz Outlet.
17.115V/230V Voltage Selector
The Amplifier has Selectable Input Voltage from 110V/60Hz ( the
Standard in USA and CANADA) to 230V/ 50Hz ( for EUROPEAN &
Some Countries of SOUTH AMERIC Operation). Please Make
Sure the Switch is In the Proper Position Before Operating,
Otherwise, the Severe Damage will be Incurred and not Covered
by Warranty.
18.Push Type Speaker Terminal
Let You Easily Connect Speaker Wires Directly to the Amplifier.
The Speaker Impedance Can be Ranged from 4 to 8 Ohms for
the General Stereo Output. The Total Speaker Impedance Must
be at Least 4- Ohm Per Channel at Stereo Mode.
19.LAN Input Port
LAN Interface Input by Router
20. REC. RCA Output
Lets You Connect the Amplifier to a Recording Unit or One More
Amplifier.
21.AUX1/ AUX2 Inputs
Lets you Connect Most High Level Audio Sources Such As CD/
DVD Player, Tape Deck, Tuner, Camcorder, or VCR, etc.
22.1/4" MIC Input Jack
Lets You Connect a Microphone with 1/4” Plug.
