Pylex CLOTHESLINE POST 10736 - Installing the E Plate

15
STEP 9 - INSTALLING THE "E" PLATE
TOP
VIEW
HOOK
PLATE
N
G1
TIGHTEN THE NUTS UNTIL
THE END OF THE THREAD
PUT THE BOLTS
AS SHOWN
KEEP "E" PLATE
HOLES
ACCESSIBLE
BACK
FRONT
NOTE: Bolts/nuts are used to prevent
lateral movement. A little
space between the bolts and the tube is normal.
LITTLE
SPACE
TUBE
PLATE
G1
E
E
N
