28
© 2005 directed electronics—all rights reserved
table of zones
A zone is represented by the number of LED flashes used by the
system to identify a particular type of input. Standard input
assignments are listed in the following table, along with spaces to
write in any optional sensors or switches that have been installed.
ZZOONNEE
(Number of
DDEEAALLEERR--IINNSSTTAALLLLEEDD
LED Flashes)
DDEESSCCRRIIPPTTIIOONN OOPPTTIIOONNSS
11
Trunk Pin
22
Instant trigger - a heavier impact
detected by the shock sensor
33
Door switch trigger
44
Instant trigger - for optional
sensors
55
Ignition trigger
66
Hood Pin
➜
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3-second delay), 1 System armed with
Bypass Notification
Disarm 2 System disarmed
Disarm 4 System disarmed with
Tamper Alert
Disarm 5 System disarmed NPC
active
