24
©
2002
Directed Electronics, Inc.
Diagnostics
The system’s microprocessor monitors and reports all active and violated zones when arming and
disarming. LED flashes indicate the active or violated zone; siren chirps indicate system status.
Arm/Disarm Diagnostics
The number of siren chirps will indicate the status of the alarm when arming and disarming. For
information on which zone is active or has been violated refer to the Table of Zones.
System Status Chirps
Table of Zones
NOTE: The Warn Away® response does not report on the LED.
Zone No. Trigger type Input description
1 Instant H1/6 BLUE - Connect to optional hood/trunk pins.
2 On-board shock sensor Heavy impact detected by the on-board shock
sensor.
3 Two-stage, progresses from Door switch circuit. H1/5 GREEN or H1/7
VIOLET warning to full alarm
4 Multiplexed Input BLUE and GREEN wires of optional sensor
plug. Inputs shorter than 0.8 seconds will trigger
a Warn Away response, while inputs longer than
0.8 seconds will instantly trigger a full alarm
sequence and report Zone 4.
5 Two-stage (similar to doors) Ignition input. H1/9 YELLOW.
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3 second delay), 1 System armed with Bypass Notification
Disarm 2 System disarmed
Disarm 4 System disarmed with Tamper Alert
Disarm 5 System disarmed NPC® active
