3
1 Margin Depth Control
2 Edge guide
3 Punching Channel
4 Punching Handle
5 Binding Mechanism
6 Binding Handle
7 Waste tray
EDgE ALIgNMENt
The adjustable Edge Guide allows pages of various sizes
to be accurately aligned for the best punching results.
Move the edge guide left or right and stop it at the
required position. (B) Test punching the scrap sheet and
re-adjust if necessary.
PuNCHINg
With the Punching Handle on the left, align sheets or cov-
ers and insert the edge to be bound into the Punching
Channel and ensure they are aligned to the Edge Guide.
Pull the Punching Handle all the way down. (D)
The PROFESSIONAL COMB BINDER 25 can punch max.
25 sheets of 80 gsm paper at once. Punch max. 1 plastic
cover at a time. To minimize the fatigue of the PROFES-
SIONAL COMB BINDER 25, we recommend to punch max.
25 sheets every time.
Move the punching Handle upwards again and remove
the punched document.
MARgIN DEPtH CONtROL
The PROFESSIONAL COMB BINDER 25 comb binder is
equipped with a Margin Control knob for improved
document reading and paper strength. It can be turned
either clockwise or counter-clockwise to suit the size of
the document being bound. Generally a small margin
depth is required for small comb sizes and a larger margin
depth is recommended for larger comb sizes.
RECOMMENDED SEttINg
Depth 2.5: 6mm - 8mm.
Depth 3.5: 10mm - 12mm.
Depth 4.5: 14mm - 18mm.
Depth 5.5: 20mm and more.
BINDINg
Place a plastic comb with the side to be opened upwards
onto the Binding Mechanism. Push the Punching Handle
so far that the comb is opened enough.
t
Position the punched sheets vertically in the open
comb. Locate the punched holes over the open
comb ngers and rotate the sheets forward onto
the comb. (g) When all the sheets are loaded
onto the plastic comb, release the Binding Handle
to its original position to close the plastic comb
completely. You can now remove the bound booklet
and enjoy your nished work.
EMPtyINg tHE wAStE tRAy
Take out the waste tray from the front side of the
machine. (I) For best results, empty the tray
regularly.
StORAgE
Close all lids and move handles to rest position.
gENERAL SAFEguARDS
Place the comb binder on a secure and stable work
table to prevent it from falling and causing personal
injury and damage to the machine.
Use the machine only for its intended purpose.
Always test the machine with some scrap paper
before punching the nal document.
When punching plastic covers, we recommend to
punch the cover with a sheet of paper on both sides.
Empty the waste tray regularly.
Lift the machine from the bottom, not from the lids
or handles.
Unauthorised maintenance is not allowed.
tECHNICAL DAtA
Punching capacity: 25 sheets (80gsm).
Number of punches: 24.
Binding capacity: 450 sheets.
max. Document size: 360mm.
Max. Binding Comb: 51mm.
Variable punching margin: 2mm - 5mm.
