8
QIO-GP8x8
(1x)
QIO-GP8x8
(2x)
GPIO connector
(black)
(2x)
Power connector
(black)
(2x)
Surface mounting
bracket
(4x)
Foam spacer
(4x)
M4 x 6 mm pan head
screws
(1x)
Warranty
statement
(1x)
Safety and
regulatory
statements
QIO-S4
(1x)
QIO-S4
(4x)
Serial connector
(black)
(2x)
Power connector
(black)
(2x)
Surface mounting
bracket
(4x)
Foam spacer
(4x)
M4 x 6 mm pan head
screws
(1x)
Warranty
statement
(1x)
Safety and
regulatory
statements
