9
QIO-IR1x4
(1x)
QIO-IR1x4
(1x)
IR Output connector
(black)
(1x)
IR Input connector
(black)
(2x)
Power connector
(black)
(2x)
Surface mounting
bracket
(4x)
Foam spacer
(4x)
M4 x 6 mm pan head
screws
(1x)
Warranty
statement
(1x)
Safety and
regulatory
statements
QIO-LVR4
(1x)
QIO-LVR4
(4x)
Relay connector
(black)
(2x)
Power connector
(black)
(2x)
Surface mounting
bracket
(4x)
Foam spacer
(4x)
M4 x 6 mm pan head
screws
(1x)
Warranty
statement
(1x)
Safety and
regulatory
statements
