Dimensions Abmessungen
16
PTH Series
User Manual
PROTECT
SIGNAL
NLR
READY
CH 1
TCL
LIMITER
0
2
4
6
8
10
12
14
18
24
• dB
PROTECT
SIGNAL
NLR
READY
CH 2
TCL
LIMITER
0
2
4
6
8
10
12
14
18
24
• dB
PTH 9 2 x 900W PROFESSIONAL POWER AMPLIFIER
POWER
BRIDGED MONO O PERATION: INPU T SEL ECTOR SWITC H TO BRIDGED
POSITION. INPUT SIGNAL TO CH. 1 ONLY. CONNECT SPKR TO 1+ AND 1- OF
BRIDGED OUT CONNECTOR. MATCH CH. 1 AND CH. 2 GAINS ON THE FRONT
12 3
Input
1 = SIGNAL GROUND
2 = SIGNAL +
SPEAKER OUT 1
1+ = SIGNAL CH. 1
1 - = GROUND CH. 1
2+ = SIGNAL CH. 2
SPEAKER OUT 2
1+ = SIGNAL CH. 2
1 - = GROUND CH. 2
BRIDGED OUT
1+ = SIGNAL CH. 1
1 - = SIGNAL CH. 2
2+ = GROUND CH. 1
MODE
PARALLEL
DUAL
BRIDGED
DIRECT
OUT
INPUT
WARNING! HA ZARDOUS ENERGY !
MAKE PROPER SPEAKER CONNECTIONS.
WARNING THIS APPARATUS MUST BE EARTHED TO
REDUCE
THE RISK OF ELECTRIC SHOCK. DO NOT
CAUTION NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED PERSONNEL.
AVIS RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR
1 2
1 2
SPEAKER OUT
BRIDGED
OUT
MIN. 4 OHM
MIN.
2 OHM
PTH9-01BB
SERIAL NR: PTH9-01BB-0001
DATE OF MANUFACTURE: 28.06.01
POWER REQUIREMENTS:
210-244V AC 50/60Hz 4100W MAX
C AU TIO N
R IS K O F E L EC T RI C
S HOC K
!
r
MADE IN BELGIUM
450
4
437
445
482
88.9
55
To Next Page
