•Heavy Oils: A degreaser or solvent-based cleaner may be required to remove heavy oil or grease
from a surface and should be followed by cleaning with IPA/water.
•Abrasion: Abrading a surface, followed by cleaning with IPA/water, can remove heavy dirt or
oxidaon and can increase surface area to improve adhesion.
•Porous Surfaces: Most porous and fibered materials such as wood, particleboard, concrete etc.
need to be sealed to provide a ed surface.
•Unique Materials: Special surface preparation may be needed for glass and glass-like materials,
copper and copper containing metals and plascs or rubber that contain components that
migrate (e.g. plasticizers).
•To obtain opmum adhesion, the bonding surfaces must be well ed, clean and dry.
Typical surface cleaning solvents are IPA/ water mixture (rubbing alcohol) or heptane. * (Steps A and B)
•Bond strength is dependent upon the amount of adhesive-to- surface contact developed.
Firm applicaon pressure develops br adhesive contact and helps improve bond strength.
(Steps C and D) Generally, this means that the tape should experience at least 1psi (100 kPa)
in roll down or platen pressure. (Sources- page #4)
•Ar applica, the bond strength will increase as the adhesive s onto the surface. At room
temperature, approximately % of the ulmate strength will be achieved ar 20 minutes, 90%
ar 24 hours and 100% ar 72 hours. In some cases, bond strength can be increased and
ulmate bond strength can be achieved more quickly by exposure of the bond to elevated
temperatures (e.g. °F [66°C] for 1 hour).
Most substrates are best prepared by cleaning with a :0 mixture of isopropyl
alcohol (IPA) and water* prior to applying Tapes. There are excepons!
◎ Excepons to this general procedure that may require addial surface preparaon include:
◎ General Procedure
NOTE : These cleaner solus contain greater than 0 g/l of volae organic compounds (OC).
Please consult your local Air Quality Regulaons to be sure the cleaner is compliant.
When usin
g solvents, be sure to follow the manufacturer’s precaus and direcs
for use when handling such materials.
IPA
&
Water
Step A:
Solvent wipe
Step B:
Wipe dry
Step C:
Apply tape to surface
Step D:
Roll ished joint
Removal
STEP 1
Remove the top screw
connecg the TD-1070
to the bracket
STEP 2
With both hands supporg
the top and bom of the
TD-1070 , carefully t the top
secon of TD-1070 downward 30°
STEP 3
Gently pull the TD-1070
down to remove from bracket
STEP 4
Apply hot air gun to the
tape beneath bracket
unl loose
Slowly pull the tape and the
bracket downward othe surface
Discrete Cable Outlets
The TD-1070 is designed for landscape or portrait installaon with a discreet
cable management system.
◎ DO NOT remove bracket or tape from surface forcefully. Excessive force during
removal may lead to damaged surface.
NOTE:
CARE AND WARNING
◎ WARNING :
Changes or mcas to this unit not expressly approved by the party responsible for
compliance will void the user’s authority to operate the equipment.
◎ Correct disposal of this product :
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, use the return and collecn systems or
contact the retailer where the product was purchased. They can take this product for
environmental safe recycling.
◎ The power consump
n of the product in networked standby is W which all wired network ports
are connected and all wireless network ports are acated.
◎ FCC & CE RF radiaon Exposure Statement Cauon :
To maintain compliance with the FCC & CE`s RF exposure guidelines.
Place the product at least 20cm from nearby persons.
NOTE : Operag Temperature: 0~ 40°C
Qbic Technology Co.,Ltd.
26F.-12,No.99.Sec.1, Xintai th Rd., Xizhi Dist., New Taipei City 221, Taiwan(R.O.C)
Tel: 886-2-2697-2000 FAX:886-2-2697-2868
◎ NOTE :
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 1of the FCC Rules. These limits are designed to provide reasonable protecn
against harmful interferenc
e in a residenal installaon. This equipment generates, uses,
and can radiate radio frequency energy, and if not installed and used in accordance with the
instrucons, may cause harmful interference to radio communicas.
However, there is no guarantee that interference will not occur in a parcular installa.
If this equipment does cause harmful interference to radio or television recep, which can be
determined by turning the equipment oand on, the user is encouraged to try to correct the
interference by one or more of the following measures :
•Reorient or relocate the receiving antenna.
•Increase the separaon between the equipment and receiver.
•Connect the equipment int
o an outlet on a circuit dint from that to which the receiver is connected.
•Consult the dealer or an experienced radio/panel PC technician for help.
This device complies with Part 1of the FCC Rules. Operaon is subject to the following two condis :
•May not cause harmful interference.
•Must accept any interference received, including interference that may cause undesired opera.
type
CAUTION
Ris
of explosion if the battery is replaced by an incorrect
Wait one-half hour after switching off before
handling parts
◎
QTD05001UKB01
Model：WA-30P12R
INPUT：
OUTPUT：
30°
