QEO FMM5 - Technical Data

13
EN
Technical data
Multimeter Max. Range Resolution Accuracy
Voltage DC 600V 0,1 mV ± 0,5 % ±2*
Voltage AC 600 V 100 mV ± 1,2 % ±10*
Current DC 10 A 0,1 µA ± 1,0 % ±2*
Resistance 20 MΩ 0,1 Ω ± 0,8 % ±2*
Environment Max. Range Resolution Accuracy
Light (luminosity) 20.000 Lux 0,1 Lux ± 0,5 % ±10*
Sound 100 dB 0,1 dB ± 3,5 dB
Humidity 95 % RH 0,1 % RH ± 5,0 % RH
Temperature -20 °C - +200 °C 0,1 °C ± 3,0 % ±1*
-20 °C - 1300 °C 0,1 °C ± 3,0 % ±5*
* digital
Display
Functions
Polarity
Over-range
Battery status indication
Measurement rate
Operating temperature
Storage temperature
Power supply
Size
Weight
Accuracy is given at 18°C to 28°C, less than
70 % RH.
1999 counts LCD display with following
Lux, °C, % and dB
Automatic, (-) negative polarity indication
“OL” mark indication
The “BAT” symbol is displayed when the battery voltage drops
below the operating level.
1.5x times per second, nominal
0°C to 50°C at < 70 % relative humidity
-10°C to 60°C at < 80 % relative humidity
1 x 9V battery
121 x 60 x 50 mm
280 g
35 - 100dB
0,1dB
30Hz - 10KHz
C–weighting
Fast
+3.5 dB at 94 dB sound level, 1KHZ ine wave
Electric condenser microphone
SOUND LEVEL
Measurement range
Resolution
Typical instrument frequency range
Frequency weighting
Time weighting
Accuracy
Microphone
