DC Current
Range Resolution Accuracy
200uA 0.1uA +1.0 % of rdg + 2 dgts
200mA 100uA +1.2 % of rdg + 2 dgts
10A 10mA +2.0 % of rdg + 5 dgts
Overload protection: 0.2A / 250V fuse (10A range unfused)
Measuring voltage drop: 200mV
Resistance
Range Resolution Accuracy
200Ω 0.1 Ω +0.8 % of rdg + 4 dgts
2 kΩ 1 Ω +0.8% of rdg + 2 dgts
200 kΩ 100 Ω +0.8% of rdg + 2 dgts
2 MkΩ 1 kΩ +1.0 % of rdg + 2 dgts
Overload protection: 15 seconds maximum 250V DC or 250V AC rms. on all ranges
Maximum open circuit voltage: 2.8V
Transistor hFE
Range: 0~1000
Base current: 10uA dc approx. (Vce = 2.8V dc)
Diode and continuity check
Diode: Test current 1.4mA DC and open circuit voltage 2.8V DC
Continuity: Built-in-buzzer will sound if the circuit resistance is less than 100Ω
Overload protection: 15 seconds maximum 250V DC or 250V AC rms.
POWER SUPPLY
B
Before first use or if the battery status indication shows a low battery („BAT“) a new battery must be
inserted. Power off the instrument, open the battery case and insert a new battery. Take care to correct
polarity and close the battery cover.
