8
Stand tube
Base
Latch to hold
the stand
Tighten with
the long screw
2. Fix the rear guard (5)
• Remove the blade assembly nut (2) and the rear guard nut (4) from the engine shaft (6).
• Position the rear guard (5) onto the engine shaft (6) while ensuring that the mark “I”
on the rear guard (5) is up.
• Then re-position the rear guard nut (4) onto the engine shaft (6), and tighten it to
secure the rear guard (5).
3. Fix the blade assembly (3)
• Fully position the blade assembly (3) onto the engine shaft (6).
• Then tighten the blade assembly (3) by fastening the blade assembly nut (2).
4. Fix the front guard (1)
• Position the front guard (1) over the rear guard (5) while ensuring the marks “I” and
“II” on the front guard (1) are up, and align the mark “I” on the front guard (1) with the
mark “I” on the rear guard (5).
