77
EN
2 . TEC HN I C A L D A TA
Rated voltage/power input 220 - 24 0 V/AC, 27 W
Maximum air output ( F) 4 4 .22 m³ /min
Service value ( SV) 1.87 ( m³ /min) /W
Standby energy consumption ( P
SB
) 0.266 W
Fan sound power level ( LW A)
58.22 dB ( A) ( high speed) ;
32.03 dB ( A) ( low speed)
Maximum air speed ( c) 4 .11 metres/sec
Service value measurement standard I EC 6087 9:1986
D imension 4 00 x 365 x 1000 mm
W eight 4 kg
D elivery content
1 x stand fan; 1 x remote control with
a CR2025 battery; 1 x user manual
3 . D ESC RI PTI ON
3 . 1 M a i n u n i t
1. Front guard
2. B lade assembly nut
3. B lade assembly
4 . Rear guard nut
5. Rear guard
6. Engine shaft
7 . Carry handle
8. Engine unit
9. Stand tube
10. Mains cable with plug
11. B ase
12. I R sensor
13. Control panel and display
14 . Safety screw
3 . 2 Re m o t e c o n t r o l
15. Power button
16. Speed up button
17 . Switch-on timer button
18. O scillation button
19. Mode button
20. Switch-off timer button
21. Speed down button
22. D isplay brightness button
4 . I N STA LLA TI ON
After unpacki ng, check for completeness of delivery and for shipping damage. I f yo ur
delivery is damaged or incomplete, please contact our after-sales service.
1 . Fi x t h e s t a n d t u b e ( 9 ) t o t h e b a s e ( 1 1 )
• Firmly and fully insert the stand tube ( 9) onto the protruding connector on the base
( 11) , then turn the stand tube until it clicks into place. The click sound indicates that
the latch on the bottom of the base has locke d the inserted stand tube. Then use the
supplied long screw to tighten the stand tube from the base bottom.
