8. Place the door back on.Ensure the door is aligned horizonally and vertically so that the seals
are closed on all sides before nally tightening the top hinge.
9. Insert the hinge bracket and secure it to the top of the unit.
10. Use a spanner to tighten it if necessary
11. Put the hinge cover and the screw cover back.
5. INSTALLATION
5.1. SPACE REQUIREMENT
■ Keep enough space for door open.
■ Keep at least 50mm gap at two sides and back.
Note: this refrigerating appliance is not intended to be used as a built-in appliance
A 480
B 450
C 850
D min=50
E min=50
F min=50
G 960
H 930
5.2. LEVELLING UNIT
■ To do this, adjust the two levelling feet in front of the unit.
■ If the unit is not level, the door s and magnetic seal alignments will not be covered properly.
ShortenLengthen
