12
EN
6. DOOR REVERSAL
1. Make sure that your refrigerator is unplugged.
2. Pry the hinge cover up and o󰀨, remove the three screws that secure the upper
hinge to the door, then remove the hinge.
Hinge cover
Screws
Upper hinge
3. Remove the freezer compartment door from the cabinet.
4. Remove the screws that secure the lower hinge to the right side of the cabinet,
then remove the hinge.
Lower hinge
Screws
5. Remove the washer and nut that secure the pin shaft to the right hole on the lower
hinge, then remove the shaft.
Pin shaft
6. Insert the pin shaft into the left hole on the lower hinge, then secure the shaft with
the washer and nut.
Pin shaft
7. Install the lower hinge on the left side of the cabinet.
8. Remove the screw that secures the door stop from the bottom right of the freezer
compartment door, then remove the door stop and install to the bottom left side.
Door stop
Freezer door
9. Install the freezer compartment door.
