10. Move the door bushing from the top right side of the freezer door to the top left
side of the door. And move the left hole cover to the right side.
Door bushing
Hole cover
11. Remove the hole cover from the top left side of the cabinet and secures the cover
on the top right side of the cabinet.
Hinge screw
hole cover
12. Secure the upper hinge to the top left side of the cabinet with the three screws you
removed previously. Before you tighten the upper hinge screws, make sure that
the top of the door is level with the cabinet and that the rubber gasket makes a
good seal.
Hinge cover
Screws
Upper hinge
13. Install the hinge cover over the hinge on the top left side of the cabinet.
Note: Ensure the rubber gaskets are making a good seal with the cabinet all the way
around the doors before tightening the hinge screws.
