8
EN
2. TECHNICAL SPECIFICATIONS
3. PRODUCT DESCRIPTION
1. Thermostat knob
2. Flip cover
3. Freezer drawers
4. Adjustable feet
4. INSTALLATION
4.1. INSTALLATION LOCATION
1. Ventilation condition
The position you select for the refrigerator installation should be well-ventilated and has
less hot air.
Do not locate the refrigerator near a heat source such as cooker, and avoid
it from direct sunlight, thus guaranteeing the refrigeration eect while saving
energy consumption.
Do not locate the refrigerator in a damp place, so as to prevent the refrigerator
from rusting and leaking electricity.
The result of the refrigerant charge amount of the refrigerator being divided by the total
space of the room in which the refrigerator is installed shall be less than 8g/m³.
Note: The amount of refrigerant charged for the refrigerator can be found on the
nameplate.
2. Heat dissipation space
When working, the refrigerator gives o heat to surroundings. Therefore, at least
30 mm of free space should be spared at the top side, more than 100 mm on both
sides, and above 50 mm at the back side of the refrigerator.
Dimensions in mm:
W D H A B C (°) E F
540 550 1440 910 1053 125±5 50 100
Power supply 220 - 240 V~, 50 Hz
Rated current 0.7 A
Energy consumption 192 kWh/year
Protection class I
Climate class N/ST
Total volume 177 L
2-Star compartment volume 28 L
4-star compartment volume 149 L
Freezing capacity 8kg/24h
Refrigerant and inject amount R600a/70g
Net weight 40 kg
