B ISTOTNE CZĘŚCI
JEDNOSTKA WEWNĘTRZNA Jednostka wewnętrzna
a
Filtr powietrza (wyciągnij)
b Panel przedni
c Louver
d Wyświetl okno
e Pilot zdalnego sterowania
JEDNOSTKA ZEWNĘTRZNA
Jednostka zewnętrzna
k Przewód łączący, rura odprowadzająca
l
Wlot powietrza (z boku oraz z tyłu)
m Wylot powietrza
UWAGA!
Wszystkie ilustracje zamieszczone w niniejszej instrukcji oraz na pudełku opakowania służą jedynie
jako objaśnienie, dlatego mogą one w pewnym stopniu różnić się wyglądem od zakupionego
klimatyzatora. Decydujący jest tu rzeczywisty wygląd urządzenia.
G
WSKAŹNIKI FUNKCJI NA PANELU WYŚWIETLACZA JEDNOSTKI ZEWNĘTRZNEJ
