50
Wall mounting plate
Front panel
. Power cable
. Louver
Functional filter
Drainage pipe
Signal cable
Refrigerant piping
Remote controller
Remote controller holder
Outdoor unit power cable
G
ATTENTION
This illustration is for explanation and indication purposes only. The illustration may be different
from the air conditioner you purchased.
4
50
