Qlogic FIBRE CHANNEL HBA

5
Step 4. Install the SANsurfer FC HBA Manager
To install the SANsurfer FC HBA Manager from the CD:
1. Select your applicable operating system.
2. Click I Accept on the License Agreement.
3. Select your specific operating system.
4. Select the SANsurfer FC HBA Manager install file.
5. Follow the on-screen directions to complete the installation.
Congratulations! You have successfully installed your QLogic HBA!
❑ To obtain the most current drivers, management tools, user instructions, and documentation, please visit the
QLogic website at h
ttp://support.qlogic.com/support/drivers_software.aspx and download the latest versions.
❑ The following section contains additional information about the QLogic HBA, including the LED scheme,
troubleshooting, warranty, technical support and certification information.
HBA LEDs
QLA2310/QLA200 HBA LED Scheme
Green LED Yellow LED Activity
❍ ❍ Power off
● ● Power
● ❍ Online
❍ ● Link
❍
Flashing
Loss of
synchronization
Green and Yellow LEDs flashing
alternately
Firmware error
QLA24xx/QLE24xx/QEM2462 HBA LED Scheme
Yellow LED Green LED Amber LED Activity
❍ ❍ ❍ Power off
● ● ● Power on (before firmware init)
Flashing Flashing Flashing Power on (after firmware init)
Yellow, Green, and Amber LEDs flashing alternately Firmware error
❍ ❍ ●/Flashing Online, 1Gbps link / I/O activity
❍ ●/Flashing ❍ Online, 2Gbps link / I/O activity
●/Flashing ❍ ❍ Online, 4Gbps link / I/O activity
Flashing ❍ Flashing Beacon
QLA234x/QLA210/QLE220 HBA LED Scheme
Green LED Amber LED Activity
❍ ❍ Power off
● ● Power
● ❍ Online
❍ ● Link
❍
Flashing
Loss of
synchronization
Alternate
flashing
Alternate
flashing
Firmware error
Flashing ❍ Beacon
