QSC Q-SYS NV-32-H - Rack Mounting Configurations (Continued); Two Units in 19-inch Rack; Half Rack Mount

5
TD-001543-01-C
C. Two Q-SYS NV-32-H (Core Capable)'s 19-inch Rack
1. (x2)
2. (x2)
3. (x2)
4. (x6)
5. (x1)
6. (x6)
4
3
3
5
1
1
6
2
6
4
Front Panel
Bottom Side
Unit 2
Bottom Side
Unit 1
Front Panel
D. One Q-SYS NV-32-H (Core Capable) Half Rack
1. (x1)
2. (x2)
3. (x6)
3
2
2
1
3
Top Side
Front Panel
