QTAC 85 EMS-C - Page 5

Page | 5
Figure 2 - Pump Components
All Valves Shown in the Open Position
1
Pressure Gauge (HP units only)
5
1” Pump to Reel Valve
2
Pump Primer Port
6
Tank to Pump Valve
3
1” NPSH Aux. Discharge Valve
7
Draft Hose Port
4
1” Pump to Tank Valve
8
Pump Drain Port
6
2
3
8
7
1
4
2
3
4
5
6
7
8
5
MEDIUM
PRESSURE
HIGH
PRESSURE
