Qtx 3D SPIRO 2.0 - DMX Channel; DMX Channel Functions

152.760UK User Manual
152.760UK User Manual
DMX CHANNEL
DMX
VALUE
DESCRIPTION
1 (Mode)
000-010 Blackout
011-062 Sound to light
063-125 Auto Mode
126-189 DMX 512 Mode 1
190-255 DMX 512 Mode 2
2 (Pattern Select)
000-255 Laser Pattern select (when CH1 in DMX mode 1)
000-255 Laser Pattern select (when CH1 in DMX mode 2)
3 (X Movement)
000 No rotation
001-120 Adjust position
121-185 Auto left / right movement
186-255 Auto left / right movement cycle
4 (Y Movement)
000 No rotation
001-120 Adjust position
121-185 Auto up / down movement
186-255 Auto up / down movement cycle
5 (Zoom in/out)
000 No zoom in/out
001-100 Manual adjust
101-150 Zoom out
151-200 Zoom in
201-255 Zoom in/out
6 (X axis rotating)
000 No rotation
001-110 Manual rotate position
111-255 Auto rotating position
7 (Y axis rotating)
000 No rotation
001-110 Manual rotate position
111-255 Auto rotating position
8 (Z axis rotating)
000 No rotation
001-140 Manual adjust position
141-217 Auto clockwise rotation
218-255 Auto anti-clockwise rotation
9 (Colour select) 000-255 Colour selection
10 (Scanning
Speed)
000-255 Control the scanner speed of the patterns
