75
Fig. 01
QSI0068
6.17 LICENCE PLATE LIGHT
Before carrying out any of the operations described be-
low, rest the vehicle on its centre-stand and ensure
To replace the license plate light bulb, proceed as follows:
• Release the screw shown in the figure.
• Rotate and then remove the bulb retainer «1»
To avoid cable damage, do not pull the bulb retainer using
the cables.
• Detach the bulb «2» from the retainer.
• Replace the bulb «2» with a new one.
Licence plate: 12V 5W
• Refit the license plate light unit following the above procedure in
reverse order.
It is highly recommended that you have these
operations performed by an authorised service
centre or qualified personnel.
(Fig. 01)
MAINTENANCE VEHICLE
