3
12. Use this heater only as described
in this manual. Any other use
not recommended by the manu-
facturer may cause fire, electric
shock, or injury to persons.
13. Avoid the use of an extension
cord.
SAVE THESE INSTRUCTIONS
FOR FUTURE USE.
General Information
This convection heater is intended
for permanent wall-mounting with
the provided brackets, which must
be operated with a line voltage ther-
mostat. (The line voltage thermostat
is not provided with the heater.)
The heater has a thermal cut-off pro-
tection. If the thermal cut-off protec-
tion trips, switch off the power. The
unit should reset automatically after
10 minutes. If the thermal cut-off
protection trips again, determine the
reason for overheating.
Specifications
Model QCC-1000W
Volts 240
(CD1)
V AC
Watts 1000 W
Height 443 mm (17.4 in)
Width 581 mm (22.9 in)
Depth 102 mm (4.0 in)
S A F E T Y I N S T R U C T I O N S / I N S TA L L AT I O N
Model QCC-1500W
Volts 240
(CD1)
V AC
Watts 1500 W
Height 443 mm (17.4 in)
Width 726 mm (28.6 in)
Depth 102 mm (4.0 in)
Model QCC-2000W
Volts 240
(CD1)
V AC
Watts 2000 W
Height 443 mm (17.4 in)
Width 889 mm (35 in)
Depth 102 mm (4.0 in)
Installation
Tools required:
- Electric drill
- Phillips (cross-head) screwdriver
- Tape measure
Do not install heater closer than 152
mm (6 in) to a vertical or horizontal
surface. This minimum distance
must be maintained.
