IDENTIFICATION DES COMPOSANTS
1
Couverture arrière
Couverture avant
Rivets de verrouillage à pression
Acher
Bouton ON / OFF
Buse
Rivets de verrouillage à pression
2
3
4
5
6
7
M80 T - PLUS
M80 T - PLUS
M80 T
M80 T
38
