Chapter 1
16
QBOX-1000 User’s Manual
USB
The USB (Universal Serial Bus) port is compatible with USB devices such as
keyboards, mouse devices, cameras, and hard disk drives. USB allows many
devices to run simultaneously on a single computer, with some peripheral acting as
additional plug-in sites or hubs.
MIC-IN
The microphone jack is designed to connect the microphone used for video
conferencing, voice narrations, or simple audio recordings.
Headphone Jack
The stereo headphone jack (3.5mm) is used to connect the system’s audio out
signal to amplified speakers or headphones.
Power LED
The power LED will light when the PC is power-on.
HDD LED
The hard disk LED blinks when data is being written into or read from the HDD.
Reset Button
To reset the computer, use the tip of a pen to press the Reset button briefly (for
less than three seconds).
Power Switch
The power switch allows powering ON and OFF the system.
