Chapter 2
23
QBOX-1000 User’s Manual
Mounting your PC to a monitor
1. Secure the VESA mounting kit (optional accessory) to your monitor with
four screws.
Figure 9 VESA mounting (1)
NOTE
To fasten the metal shelf, your monitor must comply with VESA75 or
VESA100 standard.
2. Place the QBOX-1000 on the VESA mounting kit and make sure the
computer is fitting well on the bracket.
Figure 10 VESA mounting (2)
NOTE
When mounting the unit on the wall with a display. The total weight of the
unit and display won’t exceed 7 Kg.
