QUANTOR MINICHILLY SB - Noise Emission; Technical Data; Declaration of Conformity

10
8. Noise emission
70 dB (A) data according to EN 292 part 2 A1
At level, which are lower as or equal 70 dB (A), the inscription "70 dB (A)" is adequate.
9. Technical Data
 Refrigerant: R134a
 Voltage: 115 V / 1 Ph / 60 Hz
 Water tank volume: 27 l (MiniCHILLY 05 SB Comp und 09 SB Comp)
48 l (MiniCHILLY 17 SB Comp)
 Water connections: 3/8”
 Casing: Stainless steel
 Mobile on wheels
10. Declaration of conformity
We, WTG-Quantor GmbH, D-54343 Föhren, declare in sole responsibility that the cooling units
MiniCHILLY 05, MiniCHILLY 09 and MiniCHILLY 17 which this declaration refers to, comply with the
following standards and normative documents.
- EN 60204-1 (VDE 0113)
- DIN 6650
In accordance with the low-voltage directive 2014/35/EU, EG 1935/2004.
This declaration becomes void for any modification of the units not agreed with us.
Föhren, 19.07.2016
……………………………………………………
Markus Milz
Managing director WTG-Quantor GmbH
