780 Handheld Test Instrument Page 70
Use the following procedures to test the video from an HDMI source device. You can view the incoming video and check
the video and timing parameters of the incoming video.
1. Make the physical connection between the 780 HDMI IN port and the source device under test using the
configuration instructions above or by following the instructions on the screen.
2. Touch select Installer Test from the top level menu shown below.
3. Touch select Source Test from the Test Selection menu shown below.
4. Touch select the OK activation button to initiate the test.
