11
Figure 5. Quantum/Jazzy 1450 Series Power Chair with
Synergy Seating System
ASSEMBLY
Figure 8. Unoccupied Transit System Securement Points
Front of vehicle
Figure 7. Controller Harness Routing on a Contour Seat
Wire Ties
Wire Ties
To Power Base
Figure 6. Controller Harness Routing on a Synergy Seat
