Battery Set Configuration:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wire to Red Positive (+) Terminal Posts.
Connect Black wire to Black Negative (-) Terminal Posts.
Figure 18. Battery Installation
Battery Wiring Diagram Label
Front Battery
Rear Battery
Yellow
Thumbscrews
Quick Release
Battery Connectors
Rear Cover
