CARE AND MAINTENANCE
Battery Set Configuration:
+ = Positive (Red) Terminal Post
- = Negative (Black) Terminal Post
Connect Red wire to Red Positive (+) Terminal Posts.
Connect Black wire to Black Negative (-) Terminal Posts.
Figure 21. Battery Installation
Battery Wiring Diagram Label
Release Handles
Quick Release
Battery Connectors
Front Battery
Rear Battery
Front Cover
To Next Page
