Fender Lights (Optional)
Your power chair may be equipped with fender lights. The lights are composed of three white LEDs in the
front and three red LEDs in the rear and are mounted on the fenders of your power base. See figure 5.
NOTE: Prior to initial use, ensure that the fender light switch is connected. See figure 1.
NOTE: If your power chair is equipped with an attendant control, the fender lights will activate
using the controller/single switch combination when the controller is turned on.
The fender lights are available in two version:
Operating through the controller/single switch combination
Operating through only a single switch
To activate the fender lights unsing the controller/single switch combination:
1. Turn on the power to the controller.
2. Deflect the joystick in any direction.
To deactivate the fender lights using the controller/single switch combination:
1. Turn off the power to the controller OR press the single switch.
NOTE: If the single switch is used to turn off the lights, the single switch must be used to turn
the lights back on before the lights will operate through the controller.
When the power chair is turned off, the fender lights will reset to the automatic on/off feature, if your
power chair is so equipped.
If operated through the controller/single switch combination, the fender lights will turn on when the
power chair is turned on and the joystick is deflected in any direction. The power chair must remain
powered on for the lights to stay illuminated. When the power chair is turned off, the lights will turn off.
NOTE: Turn off fender lights when the power chair is not in use to optimize power chair
performance per charge.
To operate the fender lights using only a single switch version:
1. Press the single switch once to activate the fender lights.
2. Press the single switch again to deactivate the fender lights.
NOTE: The single switch is mounted using the provided fabric fastener. The location of the
single switch should be convenient and functional for the power chair user. Possible locations
include on an armrest, the side rail, the controller, or the headrest.
NOTE: Placing the single switch on the outside of the power chair, for example, on the side rail,
may increase the overall width of the power chair.
WARNING! The single switch should be mounted in a location that is convenient for the power chair
user and where the switch harness will not be caught in drive tires or running gear, pinched in the
seat frame, or damaged when passing through doorways.
