Installation and Product Setup
QX and QXS Series Getting Started Guide 11
LEDs Description Definition
1 Unit Locator White blink — Enclosure is identified
Off — Normal operation
2 Fault/Service
Required
Amber — On
Enclosure-level fault condition exists. The event has been acknowledged but the
problem needs attention.
Off — No fault condition exists.
3 FRU OK Green — On
The enclosure is powered on with at least one power supply operating normally.
Off — Both power supplies are off; the system is powered off.
4 Temperature
Fault
Green — On
The enclosure temperature is normal.
Amber — On
The enclosure temperature is above threshold.
