Eagle 2000 – 2kW FM Broadcasting Amplifier User’s manual – Page 52 of 66
Figure 7 – Control board (1EL104) – Part list
Design Verify BOM EL104 REV.01
Scandelli Merlo
System
-
Bill Of Materials May 29,2007 15:01:03 Page1
Item Qty Reference Part PKG
-----------------------------------------------------------------------------------------------------------------------------
1 1 BT1 BATTERY 3 Ampere
2 42 CF1,CF2,C6,C8,C9,C10,C11, 100nF/50V/X7R 0805
C13,C15,C16,C17,C18,C19,
C20,C21,C22,C23,C24,C25,
C26,C27,C28,C29,C30,C31,
C32,C33,C34,C35,C36,C37,
C38,C39,C40,C41,C42,C43,
C44,C45,C47,C46,C48,C49
3 1 CN1 STRIP5x2 Passo 2,54
4 1 CN2 STRIP 3x2 Passo 2,54
5 1 CN3 STRIP 16x1 Passo 2,54 DISPLAY
6 1 CN4 DB9 CANON MASCHIO
7 1 CN5 MASCOM 4x1 Passo 2,54
8 4 C1,C2,C4,C14 10uF/16V/SMT-Elettr. CASE-B
9 2 C3,C5 10nF/50V/X7R 0805
10 2 C12,C7 18pF 0805
11 1 E1 AD22100 T092
12 1 J1 CON13x2 Passo 2,54
13 1 J2 MASCOM 2x1 Passo 2,54
14 3 LD1,LD2,LD3 LED VOLANTI
15 1 Q1 BC817 SOT23
16 2 R9,R1 10R 0805
17 19 R2,R7,R8,R10,R11,R13,R15, 10K 0805
R16,R18,R19,R20,R21,R22,
18 R23,R25,R26,R27,R28,R29
19 3 R3,R12,R14 1K 0805
20 3 R4,R5,R6 470R 0805
21 2 R30,R17 33K 0805
22 1 R24 47R 0805
23 2 SB3,SB1 SW_PUSHBUTTON chiedere dimensioni
25 1 SW1 MASCOM 5x1 Passo 2,54
26 2 U2,U1 74HCT4051 SOIC16
27 1 U3 MC34064D3,5 SO8
28 2 U4,U8 40106 SO14
29 1 U5 LMC6482 S08
30 1 U6 DS1672 SO8
31 1 U7 ATmega128 TQFP64 ( 14x14x1 )
32 1 U9 MAX202_SON SO16
33 1 Y1 16MHz HC49 Ribassato
34 1 Y2 32K768 Cilindro PTH o SMT
