Quasar SP-2725F User Manual

-10-
Parts List
REPLACEMENT PARTS LIST
Models: SP-2725F, SP-2725UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
065-02
PARTS LIST
IC050 TC74HC4066AL HALF TONE (OSD)
IC451 LA7838 V. OUT
IC551 AN78M09LB 9V REGULATOR
IC552 AN78M05LB PLUS 5V AVR
IC553 AN78M05LB PLUS 5V AVR
IC801 STRG5624A VCO (POWER SUPPLY)
IC2201 AN5829S-E1V MTS, S-AGC
IC2301 AN17800A AUDIO OUT AMP
IC2302 AN17800A AUDIO OUT AMP
COILS
L001 EXCELSA35T FERRITE BEAD
L003 TLUABTA2R2K COIL, PEAKING 2.2UH
L004 TLUABTA2R2K COIL, PEAKING 2.2UH
L005 EXCELDR35V FERRITE BEAD
L006 EXCELSA24T FERRITE BEAD
L007 EXCELDR35V FERRITE BEAD
L008 TLUABTA470K COIL, PEAKING 47UH
L009 EXCELSA35V FERRITE BEAD
L010 ELESN330JA COIL, PEAKING 33UH
L011 ELESN330JA COIL, PEAKING 33UH
L013 EXCELDR35V FERRITE BEAD
L014 ELESN180KA COIL, PEAKING 18UH
L016 EXCELSA35V FERRITE BEAD
L017 TLUABTA100K COIL, PEAKING 10UH
L018 TLUABTA150K COIL, PEAKING 15UH
L019 EXCELDR35V FERRITE BEAD
L090 EXCELSA24T FERRITE BEAD
L104 TLUABTA2R2K COIL, PEAKING 2.2UH
L108 EXCELSA35V FERRITE BEAD
L245 EXCELSA35V FERRITE BEAD
L250 EXCELSA35V FERRITE BEAD
L306 TLUABTA2R2K COIL, PEAKING 2.2UH
L325 EXCELSA35V FERRITE BEAD
L351 TLTABT101K COIL, PEAKING
L403 TLUABTA2R2K COIL, PEAKING 2.2UH
L416 EXCELSA39V FERRITE BEAD
L551 ELH5L7103 COIL
L801 ELF20N020A COIL, 2UH
L802 TALL08T470KA LINE FILTER
L803 TALL08T680KA LINE FILTER
L805 TALL08T220KA TRANSFORMER, LINE FILTER
L2305 EXCELSA35V FERRITE BEAD
L2350 ELESN4R7JA COIL, PEAKING 4.7UH
TRANSISTORS
Q001 2SD601ARTX TRANSISTOR
Q006 2SB709ARTX TRANSISTOR
Q007 2SB709ARTX TRANSISTOR
Q008 2SB709ARTX TRANSISTOR
Q009 2SC1473A TRANSISTOR
Q050 2SB709ARTX TRANSISTOR
REF
NO.
PART NO. DESCRIPTION
Q051 2SB709ARTX TRANSISTOR
Q052 2SB709ARTX TRANSISTOR
Q053 2SD601ARTX TRANSISTOR
Q054 2SD601ARTX TRANSISTOR
Q055 2SD601ARTX TRANSISTOR
Q090 2SB709ARTX TRANSISTOR
Q092 2SB709ARTX TRANSISTOR
Q351 2SC3063RL TRANSISTOR
Q352 2SC3063RL TRANSISTOR
Q353 2SC3063RL TRANSISTOR
Q354 2SD601ARTX TRANSISTOR
Q355 2SD601ARTX TRANSISTOR
Q356 2SD601ARTX TRANSISTOR
Q451 2SD601ARTX TRANSISTOR
Q452 2SD601ARTX TRANSISTOR
Q453 2SD601ARTX TRANSISTOR
Q501 2SC4212HLB TRANSISTOR
Q505 2SD601ARTX TRANSISTOR
Q520 2SD601ARTX TRANSISTOR
Q551 2SC5339LBMA1 TRANSISTOR
Q605 2SB709ARTX TRANSISTOR
Q606 2SD601ARTX TRANSISTOR
Q820 2SA1767QTA TRANSISTOR
Q830 2SB1011QRL TRANSISTOR
Q2350 2SB709ARTX TRANSISTOR
RELAYS
RL801 TSEH0005 RELAY
RESISTORS
R001 ERJ6GEYJ102V RES,M 1K-J-1/10W
R003 ERJ6GEYJ105V RES,M 1M-J-1/10W
R004 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R006 ERDS2TJ101T RES,C 100-J-1/4W
R007 ERJ6GEYJ471V RES,M 470-J-1/10W
R008 ERJ6GEYJ471V RES,M 470-J-1/10W
R009 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R010 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R012 ERJ6GEYJ473V RES,M 47K-J-1/10W
R013 ERJ6GEYJ202V RES,M 2K-J-1/10W
R014 ERJ6GEYJ221V RES,M 220-J-1/10W
R015 ERJ6GEYJ221V RES,M 220-J-1/10W
R016 ERJ6GEYJ221V RES,M 220-J-1/10W
R017 ERJ6GEYJ681V RES,M 680-J-1/10W
R018 ERJ6GEYJ681V RES,M 680-J-1/10W
R019 ERJ6GEYJ681V RES,M 680-J-1/10W
R021 ERJ6GEYJ101V RES,M 100-J-1/10W
R022 ERJ6GEYJ101V RES,M 100-J-1/10W
R023 ERJ6GEYJ102V RES,M 1K-J-1/10W
R024 ERJ6GEYJ153V RES,M 15K-J-1/10W
R028 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
REF
NO.
PART NO. DESCRIPTION
